Technical data (manufacturer information, German terms)
| Außendurchmesser d1 | 13 |
|---|
| Länge l1 | 25 |
|---|
| Form | K - Kugel Kunststoff, Druckfläche plan |
|---|
| Werkstoff | ST - Stahl |
|---|
| Gewinde | M 5 |
|---|
| d3 | 8,5 |
|---|
| d4 Kugel-Ø | 10 |
|---|
| l2 | 14,7 |
|---|
| Statische Belastbarkeit Form B | 20 |
|---|
| Form R | 9 |
|---|
| Form K | 4 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,019 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 709.7 |
|---|
| Order designation | GN 709.7-13-25-K |
|---|
| EAN | 4045525886995 |
|---|
| Manufacturer designation (German) | Pendelelemente |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84662020 |
|---|
| eCl@ss 5.1.4 | 21029090 |
|---|
