Technical data (manufacturer information, German terms)
| Vierkant s | 12 |
|---|
| Form | Z - zweiteilig |
|---|
| Werkstoff | ST - Stahl |
|---|
| b | 15 |
|---|
| d1 | M 6 |
|---|
| d2 Stift | 6 |
|---|
| h1 | 39,2 |
|---|
| h2 | 25,6 |
|---|
| l1 | 10 |
|---|
| l2 | 5 |
|---|
| l3 | 14 |
|---|
| l4 max. | 9 |
|---|
| l5 | 10 |
|---|
| l6 | 5 |
|---|
| m1 | 27,2 |
|---|
| m2 | 13,6 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,037 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 129 |
|---|
| Order designation | GN 129-12-Z |
|---|
| EAN | 4045525044241 |
|---|
| Manufacturer designation (German) | Scharniere, Stahl, 2- oder 3- teilig |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83021000 |
|---|
| eCl@ss 5.1.4 | 23250304 |
|---|
