Technical data (manufacturer information, German terms)
| Breite l1 | 114 |
|---|
| Bohrungsabstand m1 | 32 |
|---|
| Bohrungsabstand m2 | 32 |
|---|
| Farbe | LG - grau, matt |
|---|
| Kennziffer | 1 - ohne Sicherheits-Klemmhebel |
|---|
| Werkstoff | KT - Kunststoff |
|---|
| Bohrungsabstand x1 | 32,5 |
|---|
| Bohrungsabstand x2 | 32,5 |
|---|
| d1 | 6,5 |
|---|
| d2 | 8 |
|---|
| h1 | 16 |
|---|
| h2 | 8 |
|---|
| h3 | 16 |
|---|
| h4 | 38 |
|---|
| l2 | 36 |
|---|
| l3 | 57 |
|---|
| l4 | 44 |
|---|
| für Profilbreiten s1 - s2 | 60 - 60 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,050 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 159 |
|---|
| Order designation | GN 159-114-32-32-LG-1 |
|---|
| EAN | 4045525082854 |
|---|
| Manufacturer designation (German) | Scharniere für Profilsysteme, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23250304 |
|---|
