Technical data (manufacturer information, German terms)
| Werkstoff | ST - Stahl |
|---|
| Länge l1 | 50 |
|---|
| Länge l2 | 51 |
|---|
| Form | C - Befestigung von der Rückseite |
|---|
| b | 18 |
|---|
| d1 | M 8 |
|---|
| d2 Stift | 8 |
|---|
| h1 | 18 |
|---|
| h2 | 18 |
|---|
| l3 | 26 |
|---|
| l4 max. | 8 |
|---|
| l5 | 14 |
|---|
| l6 max. | 8 |
|---|
| l7 | 14 |
|---|
| m1 | 29 |
|---|
| m2 | 35 |
|---|
| Vierkant | 16 |
|---|
| t | 11 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,210 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 129.2 |
|---|
| Order designation | GN 129.2-50-51-C-ST |
|---|
| EAN | 4045525925823 |
|---|
| Manufacturer designation (German) | Scharniere, Stahl, 3-teilig |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83021000 |
|---|
| eCl@ss 5.1.4 | 23250304 |
|---|
