Flügelmuttern GN 434, Edelstahl – Ganter GN 434-NI-26-M4-MT
Dimensional drawing Ganter GN 434-NI-26-M4-MT
Preview: Flügelmuttern GN 434, Edelstahl – Ganter GN 434-NI-26-M4-MT
Preview: Dimensional drawing Ganter GN 434-NI-26-M4-MT
Flügelmuttern GN 434, Edelstahl
Flügelmuttern GN 434, Edelstahl – Ganter GN 434-NI-26-M4-MT
Dimensional drawing Ganter GN 434-NI-26-M4-MT
Mobile Preview: Flügelmuttern GN 434, Edelstahl – Ganter GN 434-NI-26-M4-MT
Mobile Preview: Dimensional drawing Ganter GN 434-NI-26-M4-MT

Flügelmuttern GN 434, Edelstahl

Product No.:
434-NI-26-M4-MT
ca. 3-5 days ca. 3-5 days (abroad may vary)
manufacturer:
Ganter Norm
    You do not have permission to view the prices

    Prices and quantity discounts are shown after you log in. No customer account yet? Register now

    Add to wish list
    Description

    Technical data (manufacturer information, German terms)

    WerkstoffNI - Edelstahl-Feinguss
    Griffdurchmesser d126
    Gewinde d2M 4
    OberflächeMT - matt gestrahlt
    Außendurchmesser11
    h110
    h24,5
    t min.7
    RoHSJa
    Gewicht0,019 kg

    Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.

    Article data

    ManufacturerGanter (Otto Ganter GmbH & Co. KG)
    Standard partGN 434
    Order designationGN 434-NI-26-M4-MT
    EAN4045525900615
    Manufacturer designation (German)Flügelmuttern, Edelstahl
    Order unitPiece
    Customs tariff number73181639
    eCl@ss 5.1.423110710
